LOMVUM T28B Auto Ranging Digital Multimeter

LOMVUM T28B Auto Ranging Digital Multimeter, 6000 Counts Electrical Tester AC/DC Amp Ohm Voltage Tester Meter

LARGE RANGE MEASURING – 6000 Counts auto-ranging multimeter, DC Voltage to 1000V, AC Voltage to 750V, AC/DC Current to 10A, Capacitance to 100mF, with type K thermocouple, quickly solve the automotive and household electrical issues.

• TRMS 6000 COUNTS DIGITAL MULTIMETER: Accurately Measures AC / DC Current, Voltage, Capacitance, Resistance, Temperature, Frequency, Diode and More, Maximum Reading over Time, Auto-ranging and Continuity Buzzer.
• TROUBLESHOOTS & SAFETY PROTECTION: Meet the requirements of 600V CAT IV 1000V CAT III, built-in explosion-proof ceramic fuse tubes, reverse Polarity protection, low battery indication, and overload protection for all ranges. Automotive and household electrical problems safely and accurately.
• LARGE BACKLIT LCD DISPLAY: Data hold and 3.0-inch large digital display with backlit LCD for visibility in dimly light areas.
• EASE OF USE: Built-in kickstand for hand-free use. Protective rubber corner guards for drop protection. Auto Shut-off and Hanging Magnet. Sampling Speed: 2-3 times per second.

specifications

• DC Voltage: 600mV/ 6V/ 60V/ 600V/ 1000V ±(0.5%+5)
• AC Voltage: 600mV/ 6V/ 60V/ 600V/ 750V ±(1%+4)
• DC Current: 600uA/ 6mA/ 60mA/ 600mA ±(1.2%+5); 20A ±(2.0%+5)
• AC Current: 600μA/ 60mA/ 600mA ±(1.5%+5); 10A ±(2.0%+5)
• Resistance: 600Ω/ 6KΩ/ 60KΩ/ 600KΩ/ 6MΩ/ 60MΩ ±(0.8%+5)
• Capacitance: 6nF/ 60nF/ 600nF/ 6μF/ 60μF/ 600μF/ 6mF/ 100mF ±(4.0%+5)
• Frequency: 9.999MHz ±(1.5%+5)
• Temperature: -20 °C~1000 °C/ -4 °F~1832 °F
• Safety Class: IEC-61010, 600V CAT IV, 1000V CAT

Package List

• 1 * Current voltage tester
• 1 * User’s manual
• 1 * Test Lead and K-Type cables Thermocouple

Downloads

T28B Datasheet
